SC405 (RFID) Access Control Terminal

SC405 is a RFID Access Control Terminal which possesses a 2.0-inch color display with graphical UI, enabling simple and easy control. It has a built-in auxiliary input function which enhances the flexibility to be connected with wired detector or emergency switch. With multi-verification methods by combinations of PIN, password and card, high level of security and flexibility are guaranteed. Moreover, the product supports USB flash drive for offline data management, as well as is equipped with multiple alarm outputs such as Tamper Proof Switch and Duress Alarm. Its convenience and adaptability allow it to be well deployed in residential housing, offices and any other public facilities.

• ID Card Capacity

  30,000

• Transaction Capacity

  80,000/100,000 (For 64M)

• Communication

  TCP/IP, RS485*, USB-Host

• Interfaces for Access Control

  3rd party electric lock, door sensor, exit button, alarm, doorbell

• Auxiliary Interface

  1ea for linkage function

• Wiegand Signal

  Output & Input, SRB

• Standard Functions

  ID Card, Automatic Status Switch, Self-Service Query, DST, 9 Digit User ID, Scheduled Bell, Anti-passback

• Optional Functions

  IC Card, Print Function

• Display

  TFT LCD Color Screen

• Power Supply

  DC 12V

• Operating Temperature

  0C 45C

• Operating Humidity

  20% 80%

• Dimension

  143 x 96 x 42mm (L*W*H)

• SDK

  Standalone SDK

• Software

  ZKBio CVAccess
